Intelligent Systems And Networking Research Lab



Faculty In-Charge:

Dr. S. Sudha, Professor, NIT-T

This laboratory was initially started as Networking labin 2005 in a small room in the Department of EEE and moved to EEE Annexein 2017 with rename as Intelligent Systems and Networking Research Lab. This lab is hosted with state-of-the art experimental research facilities required for setting up Wireless Sensor Networks and Internet of Things. This lab is envisioned to provide the researchers and students a practical experience of designing, deploying and implementing novel applications with Wireless Sensor Networks. Theresearch activities carried out in this lab are usually driven by specific application areas like landslide monitoring, Precision Agriculture, Home Automation etc..,

Equipments and Components :

SENSenuts MOTES:

  • 32-bit RISC JN 5168 Microcontroller, 1-32MHz clock speed.
  • 256KB flash, 32KB RAM, 4KB EEPROM , 128-bit AES security processor
  • 2.4 GHz IEEE 802.15.4 compliant transceiver
  • Rx current 17mA, Tx current 15mA , Controllable transmission power (-32 to +2.5 dBm)
  • 2V to 3.6V battery
  • Data Transfer rate 115200 baud 128 byte receive buffer and 256 byte transmit buffer







IRIS MOTES:

  • IEEE 802.15.4 compliant RF transceiver • 2.4 to 2.48 GHz, a globally compatible ISM band
  • 250 kbps data rate
  • RAM 8K bytes, EEPROM 4K bytes
  • Serial Communications UART
  • 0-3V transmission levels, 10 bit ADC 8 channel,
  • Interfaces Digital I/O, I2C,SP



2 Number of High Performance Workstations and 4 Number of Desktops

Sensors : Acoustic, Sound, Vibration, Automotive, Electric Current, Electric Potential, Magnetic, Weather, Moisture, Humidity, Flow, Fluid Velocity , Position, Angle, Displacement, Distance, Speed, Acceleration, Optical, Light,PressureForce, Density, Level, Thermal, Heat, Temperature, Proximity, Presence, Speed.

Microcontrollers: Arduino Uno, Raspberry Pi

Radio Modules: XBee Transceivers, CC2500

GSM, GPRS Modules, RFID Tags, Relays, Servo motors.

Regulated Power Supply and Multimeter, Automatic Number Plate Recognition Camera,

PIC programmer
