Faculty in Charge
Dr. Josephine R.L, Assistant Professor, NIT-T
Components Available in Electric drives Research Lab
S. No. |
Name of the Equipment claimed |
Quantity |
1. |
FPGA module compatible with My-Rio Zed-Board |
1 |
2. |
Power Inverter Module |
2 |
3. |
Induction motor |
1 |
4. |
Voltage (LEM LV 25-P: Qnty:02 |
2 |
5. |
Rheostat 15Ω, 5A (Qnty:02) |
2 |
6. |
Voltage sensors (LEM 25-P: Qnty:03) |
3 |
7. |
Current sensors (LEM 55-P: Qnty:03 |
3 |
8. |
PCB for sensors |
1 |
9. |
TI microcontroller (TMS320F28379D) |
1 |
10. |
3-phase 3 kW resistive load box |
2 |
15. |
Electrolytic capacitors (600 V, 1500 µF) |
2 |
16. |
Multi tapping inductors (0-10 mH, 20 A) |
4 |
17. |
Rheostat 230Ω, 1.2 A |
1 |
18. |
Rheostat 50Ω, 5 A |
1 |
19. |
Solar array simulator |
1 |
20. |
Digital Storage Oscilloscope |
1 |
