Trainer CNC

EMCO PC TURN 55-2NOS

Swing one bed	-	Ø130 mm
Swing one Cross Slide	-	Ø60 mm
Travel	-	x-axis 48mm
		y-axis 228mm
Spindle Speed	-	130-3000rpm
Feed range	-	0-800mm/min
Distance between centers	-	280mm
Spindle motor power	-	370/550W

EMCO PC MILL 55-2NOS

Table size	-	420*125mm
Travel	-	x-axis 190 mm
		y-axis 125 mm
Effective Z travel	-	120 mm
Spindle Speed	-	200-2500 rpm
Feed range	-	0-800 mm/min

TRIAC-3-AXIS MILLING MACHINE

EMCO COMPACT-CNC TRAINERS-2 NOS

RHINO X-3 ROBOTWOKCELL

AGV TRAINING SYSTEM

APPLICATIONS

All the above facilities are used by our Production Engineering, Mechanical Engineering, and P.G students.Also it is being used in CNC training for other Engineering College Students and practicing Engineers. It is also used for setting up the proposed Nodal CNC center to facilitate CNC Training.
